Model A009

SP 70-200mm F/2.8 Di VC USD

CANON EF NIKON F SONY A

Telephoto Evolved.
The next step.

Angle of View (diagonal)	34゜21' - 12゜21' (with full-size SLR cameras) 22゜33' - 7゜59' (with APS-C sized sensor digital SLR cameras)
Optical Construction	23 elements in 17 groups
Minimum Object Distance	1.3m (51.2 in)
Maximum Magnification Ratio	1:8 (at f=200mm : MFD 1.3m)
Filter Size	Φ77mm
Maximum Diameter	Φ85.8mm
Length*1	188.3mm (7.4 in)*
Full Length*2	196.7mm (7.7 in)*
Weight	1,470g (51.9 oz)* (including detachable tripod mount)
Aperture Blades	9 (rounded diaphragm)*3
Minimum Aperture	F32
Standard Accessory	Flower-shaped lens hood
Mount	CANON EF Mount (End of sale) NIKON F Mount (End of sale) SONY A Mount (End of sale)*4
Release Date	November 22, 2012 (NIKON F Mount) March 28, 2013 (CANON EF Mount) June 27, 2013 (SONY A Mount)

Specifications, appearance, functionality, etc. may be changed without prior notice.

*Length, entire length and weight values given are for the Nikon mount.
*1: Length is the distance between the mount face and the tip of the lens.
*2: Full length is the distance between the tip of the lens and the tip of the protrusion.
*3: This rounded diaphragm retains a nearly circular shape even when taken two stops down from its fully open state.
*4: The Sony mount does not include VC, as Sony digital SLR bodies include image stabilization functionality.
