FA and Machine Vision Lenses
-
219HB
-
-
2022.12
2050.01
Imager Size Focal Length Aperture Range Iris -
Motion range
Focus: 163 °
IRIS:96 °
| Model No. | 219HB | ||
|---|---|---|---|
| Imager Size | 2/3" | ||
| Mount Type | C | ||
| Focal Length | 8mm | ||
| Aperture Range | F/1.4 - F/16 | ||
| Field of View Angle (Horizontal x Vertical) |
2/3" | 59.3° x 45.2° | |
| 1/2" | 43.6° x 33.1° | ||
| 1/3" | 33.1° x 25.0° | ||
| Focus Range | 0.26m - ∞ | ||
| Operation | Focus | Manual w/lock | |
| Iris | Manual w/lock | ||
| Filter Size | M25.5 P=0.5mm | ||
| Wave Length | Visible Light | ||
| TV Distortion (D) | -3% ≦ D ≦ 0% | ||
| Weight | 48g 士 5g | ||
| Operating Temperature | -10°C - +45°C | ||
* Specificotions subjected to change without ony notice.
